منبع تغذیه سطح بالا HRP-300-36

HRP-300-36 (36V, 9A):

LRS-300-36 is a 324W single-output enclosed type power supply with 38mm of low profile design. Adopting the full range 85-264VAC input, the entire series provides an output voltage line of 3.3V, 5V, 7.5V, 12V, 15V, 24V, 36V and 48 V.

In addition to the high efficiency up to 89%, the design of metallic mesh case enhances the heat dissipation of the HRP-300 that the whole series operates from -40 °C through 70 °C under air convection without a fan. Delivering a low no load power consumption, it allows the end system to easily meet the worldwide energy requirement. HRP-300 has the complete protection functions and 5G anti-vibration capability; it is complied with the international safety regulations such as TUV EN60950-1, EN60335-1, EN61558-1/-2-16, UL60950-1, EN61000-4-2,3,4,5,6,8,11, EN55035, EN61000-6-2, heavy industry level, EAC TP TC 02. HRP series serves as a high performance power supply solution for various industrial applications.

HRP-300 Features:

• Universal AC input/Full range
• Built-in active PFC function, PF>0.95
• Withstand 300VAC surge input for 5 seconds
• High operation temperature up to 70 °C
• Protections: Short circuit / Overload / Over voltage / Over temperature
• 1U low profile 41mm
• Built-in cooling fan ON-OFF control
• Built-in remote ON-OFF control
• Built-in remote sense function
• Built-in DC OK signal
• All using 105 °C long life electrolytic capacitors
• Withstand 5G vibration test
• High efficiency, long life and high reliability
• 100 percent full load burn-in test
• 3 years warranty

• Industrial automation machinery
• Industrial control system
• Mechanical and electrical equipment
• Electronic instruments, equipment or apparatus
• Household appliances

Spec:

HRP-300-SPEC
